2560Wh Expansion LiFePO4 Battery Pack 51.2V

SKU: 12710 | VT: VT-25001
12710-2
12710-3
12710-4

“From

“Reliable

Downloads
Manual
Warranty Conditions
IEC 62619
Declaration of Conformity
SGS
Equipment Runtime
EMC License
Technical Specifications
PPWR Declaration of Conformity
Specifications

“Portable

“Portable

“Portable


General Information
Electrical Data
Wattage
2560Wh
Voltage
Nominal voltage: 51.2V Working voltage range: 40 - 57.6V
Input
Charging current input: 50A Max.
Output
Discharge current output: 70A Max.
Capabilities
IP Rating
IP20
Cells Chemistry
LiFePO4
Battery Capacity
Nominal energy 2560Wh
Nominal capacity 50Ah
Prismatic Aluminum-Cased LiFePO4 Cell
3000 Cycles
Expands the capacity of portable power station SKU 12709, Max. 6 Batteries more.
Working conditions
Operating humidity: 10% - 85%(Non-condensing)
Altitude: <2000m
Discharge Temperature Range: -20°C~45°C
Charge Temperature Range: 0°C~45°C
Storage Ambient Temperature: -20℃~45°C
Dimensions
Size
536 x 270 x 225mm
Product Data
Order code
12710
Product code
VT-25001
Item Weight
26.6kg
Items per box
1
Additional
Release Date
31.03.26
Manufacturer
V-TAC
Warranty
2 years
