125kW Hybrid Solar Inverter Three Phase High Voltage 10yrs Warranty

SKU: 12738 | VT: SUN-125K-SG02HP3-EU-GM10
12738-2
12738-3
12738-4
12738-5

Downloads
Manual
Technical Specifications
Specifications
General Information
Electrical Data
Current
  • Max. Operating PV Input Current (A) 42+42+42+42+42+42+42+42+42+42
  • Max. Input Short-Circuit Current (A) 63+63+63+63+63+63+63+63+63+63;
  • Rated AC Input/Output Current (A) 189.4/181.2;
  • Max. AC Input/Output Current (A) 204.6/195.7;
Wattage
  • Max. PV Input Power: 200000W;
  • Rated AC Input/Output Active Power: 125000W;
  • Max. PV access power: 250000W;
Phase
Three Phase
Voltage
  • Max. PV Input Voltage: 1000V;
  • MPPT Range: 150-850V;
  • Rated PV Input Voltage: 650V;
  • Start-up Voltage: 180V;
Frequency
Rated Input/Output Grid Frequency/Range(Hz) 50/45-55, 60/55-65
Power Factor
0.8 leading to 0.8 lagging
Capabilities
IP Rating
IP65
Working conditions
-40 to +60℃, >45℃ Derating
Dimensions
Size
734 x 1091 x 344 mm
Product Data
Order code
12738
Product code
SUN-125K-SG02HP3-EU-GM10
Item Weight
161.7 kg
Items per box
1
Certificates & Standards
Certification
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
Additional
Release Date
16.07.26
Brand
Deye
Warranty
10 years
