40W LED Batten Fitting Linkable Upto 5pcs Natural White

SKU: 6390 | VT: VT-80404
6389-2

Product benefits

  • Perfectly matches with the traditional daylight tube fixture
  • Ballast or Starter NOT Required. Direct AC Power
  • No flickering, No UV radiation
  • Easy to install
  • Low maintenance
  • Environment friendly
  • Long lifespan

Applications

  • Widely used for domestic or commercial lighting, office, supermarkets, shop, hotels and similar environments
Downloads
Technical Specifications

Declaration of Conformity
Product Information Sheet
Specifications
General Information
LED Chip
SMD2835
Lifespan
30 000 hrs
Electrical Data
Wattage
40W
Voltage
AC: 100-240V
Frequency
50/60Hz
Power Factor
>0.9
Technical Data
Light color
Natural White
Color Temperature
4000K
Luminous flux (lm)
3200 lm
LED Quantity
240 pcs
Color Rendering Index CRI
>80
Body Details
Material
Aluminium, Plastic
Capabilities
Starting Time 100% ON
0.001 sec (instant on)
Color stability
<6
Luminous intensity, Cd
1194.34 Cd Max.
On/Off cycles
>15000
Working conditions
Not suitable for use in extreme conditions. Normal working conditions is -25° +50°
IP Rating
IP20
Dimensions
Size
1200 x 75 x 26 mm
Product Data
Order code
6390
Product code
VT-80404
Items per pack
1
Item Weight
0,78
Item Volume
0,0036408
Items per box
10
EAN Code
3800157625111
Certificates & Standards
Energy efficiency class
G
Certification
CE, EMC, ROHS
Additional
Warranty
2 years
Additional information
Driver AC: 110-240V / DC: 30-80V; 2 x 240mA
Energy Class Graphics
Energy Class
Manufacturer
V-TAC
